385B－385B Stage III

Engine Power	61.3 kW (82hp) @ 2400 rpm	61.3 kW (82hp) @ 2400 rpm
Operating Weight	3750 kg	8267 lb
Rated Operation Capacity	1045 kg	2304 lb
Raise	4.2 s	4.2 s
Dump	2.8 s	2.8 s
Lower (empty, float down)	2.5 s	2.5 s
Tipping Load	2090 kg	4608 lb
Bucket Breakout Force	29.81 kN	6701.55 lbf
Dump Clearance - Full Height	2572 mm	8’5”
Dump Reach - Full Height	587 mm	1’11”
Engine Model	Yanmar 4TNV98T-ZCNLYSC	Yanmar 4TNV98T-ZCNLYSC
Emission	EPA Tier 3 / EU Stage IIIA	EPA Tier 3 / EU Stage IIIA
Cooling System	20 L	5 gal
Overall Length with Standard Bucket	3851 mm	12’8”
Overall Width with Standard Bucket	1850 mm	6’1”
Overall Height to top of Cab	2034 mm	6’8”
Front Clearance Radius with bucket	2339 mm	7’8”
Bucket capacity	0.5 m³	0.7 yd³

385B－385B Tier 4F / Stage V

Engine Power	53.7 kW (72 hp) @ 2400 rpm	73.01 ps
Operating Weight	3750 kg	8267 lb
Rated Operation Capacity	1045 kg	2300 lb
Raise	4.2 s	4.2 s
Dump	2.8 s	2.8 s
Lower (empty, float down)	2.5 s	2.5 s
Tipping Load	2090 kg	4608 lb
Bucket Breakout Force	29.81 kN	6701.55 lbf
Dump Clearance - Full Height	2572 mm	8’5”
Dump Reach - Full Height	587 mm	1’11”
Engine Model	Yanmar 4TNV98CT-NLYS	Yanmar 4TNV98CT-NLYS
Emission	EPA Tier 4F / EU Stage V	EPA Tier 4F / EU Stage V
Cooling System	20 L	20 gal
Overall Length with Standard Bucket	3851 mm	12’8”
Overall Width with Standard Bucket	1850 mm	6’1”
Overall Height to top of Cab	2034 mm	6’8”
Front Clearance Radius with bucket	2339 mm	7’67”
Bucket capacity	0.5 m³	0.654 yd³
