CLG764A－764A Yuchai II

Gross Power	75 kW (101 hp) @ 2200 rpm	101.97 ps
Net Power	72 kW (97 hp) @ 2200 rpm	97.89 ps
Operating Weight	8300 kg	18298.37 lbs
Maximum Digging Depth	4406 mm	14.46 ft.
Maximum speed	9.8 - 44 km/h	6-27 mph
Turning Radius Outside of Front Tire w/o single braking	4800 mm	15’9”
Turning Radius Outside of Bucket w/o single braking	/ mm	/
Turning Radius Outside of Front Tire w/ single braking	/ mm	/
Bucket Breakout Force, General bucket	52 kN	11690.07 lbf
Bucket Digging Force	52.1 kN	11713 lbf
Maximum Dump Height (Loading)	2691 mm	8’10”
Loading Height (Digging)	3586 mm	11’9”
Model	Yuchai YC4A105Z-T20	Yuchai YC4A105Z-T20
Emission Standard	EPA Tier 2 / EU Stage II	EPA Tier 2 / EU Stage II
Standard Bucket Heaped Capacity	1 m³	1.3 yd³
Standard Backhoe Bucket Heaped Capacity	0.2 m³	0.3 yd³
Download Brochure 1 Download Brochure 2

CLG764A－764A Yuchai III

Gross Power	81 kW (108 hp)	110.13 ps
Net Power	77 kW (103 hp)	104.69 ps
Operating Weight	8300 kg	18298 lb
Maximum Digging Depth	4440 mm	14.57 ft.
Maximum speed	9.8 - 44 km/h	6-27 mph
Turning Radius Outside of Front Tire w/o single braking	4800 mm	15’9”
Turning Radius Outside of Bucket w/o single braking	5850 mm	19’2”
Bucket Breakout Force, General bucket	52 kN	11690 lbf
Bucket Digging Force	52.1 kN	11713 lbf
Maximum Dump Height (Loading)	2691 mm	8’10”
Loading Height (Digging)	3586 mm	11’9”
Model	Yuchai YCA05K110-M300	Yuchai YCA05K110-M300
Emission Standard	Brazil Stage III	Brazil Stage III
Standard Bucket Heaped Capacity	1 m³	1.3 yd³
Standard Backhoe Bucket Heaped Capacity	0.2 m³	0.3 yd³
Download Brochure
